DeVillbiss Air Power Company FA100 - Manual

SPECIFICATION CHART
*A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch circuit
the air compressor is operated on. If the air compressor is connected to a circuit protected by fuses, use
quick acting fuses.
Model No.
Horsepower
SCFM @ 40 psig
SCFM @ 90 psig
Displacement CFM
Bore
Stroke
Voltage-Single Phase
Minimum Branch Circuit Requirement
*Fuse Type FA100
1.0
3.4
2.1
4.0
1 3/4"
1 1/4"
120
15 AMPS
Quick Acting
MGP-FA100 2/27/98
SAFETY GUIDELINES - DEFINITIONS
IMPORTANT SAFETY INFORMATION - A
HAZARD THAT MIGHT CAUSE SERIOUS
INJURY OR LOSS OF LIFE.
Information that you should pay special
attention to.
URGENT SAFETY INFORMATION - A HAZARD
THAT WILL CAUSE SERIOUS INJURY OR LOSS
OF LIFE.
This manual contains information
that is important for you to know
and understand. This information
relates to protecting YOUR
SAFETY and PREVENTING
EQUIPMENT PROBLEMS. To
help you recognize this informa-
tion, we use symbols to the right.
Please read the manual and pay
attention to these sections.
Information for preventing damage to
equipment.
OWNERS MANUAL FOR PERMANENTLY LUBRICATED
AIR COMPRESSOR
MODEL NO.
FA100
(For Home Use Only)
DeVilbiss Air Power Company • 213 Industrial Dr. • Jackson, TN 38301-9615
