RTA Products RTA-8336 - Manual (Page 3)

7 8 5 6
9 12 11
1 2 3 4
10
Left
Right
13
RTA-8336 P.3
A
B
D
C
6X60 MM
6X35 MM
6X12 MM
8
6
2
PART QTY. ITEM
4 4X33 MM
Estructuras Principales Tubo Horizontal Topes Panel Posterior
Panel Superior Tubos de Soporte Deslizadores Porta teclado
Soportes Laterales Panel de Impresora Panel para Cpu
Tubo Protector
Topes para Porta Cpu
Izquierdo
Derecho
LISTA DE PARTES PARTS LIST PARTS LIST
E 4
PART QTY. ITEM
6X25 MM
F 4 4X14 MM
G 4 6X30 MM
1
1
SCREWS SCREWS TORNILLOS
Main Structures Horizontal Tube Studs Back Panel
Tabletop Supporting Tubes Sliders Keyboard Panel
Lateral Suport Tubes Printer Panel CPU Panel
Protector Tube
Studs For CPU Holder
