Royer Labs SF-12 - Manual (Page 14)

Specifications
Acoustic Operating Principle:
Electrodynamic pressure gradient
Polar Pattern:
Symmetrical Figure-8
Generating Element:
Two 1.8 micron aluminum ribbons
Frequency Response:
30Hz - 15000Hz ±3dB
Sensitivity:
> -52dBv Re.1v/pa
Output Impedance:
300 Ohms @ 1 kHz
Recommended Load Impedance:
> 1500 Ohms
Maximum SPL:
> 130dB
Output Connector:
male XLR 5 pin (stereo)
Dimensions:
206mm L x 25mm W (8” L x 1” W)
Weight:
369 grams (13 oz.)
Finish:
Matte Black Chrome, Dull Satin Nickel (optional)
Accessories:
Protective wood case, one (1) 18’ shielded 5 conductor
cable with 5-pin connectors, adaptor cable terminating in
two (2) XLR type 3-pin male connectors, mic clip, mic
sock
Optional Accessories:
Shock mount, WS-12 blast filter
To learn more about Royer products and their usage, visit our website at www.royerlabs.com .
14
