Specifications

Maximum Input

Input Impedance

Output Impedance

Wah frequency Range

Current Consumption

Power Requirements

+10dBu

1M ohm

1K ohm

400Hz (Heel Down) to 2KHz

(Toe Down) 400Hz

35ma

9VDC <=300ma

* CE Approved *

WAH ON LED - This super bright blue LED will be lit when
the “wah” effect is activated. To activate the wah - see point 2.
The blue LED will not be lit when the wah is bypassed.

9-VOLT BATTERY COMPARTMENT - to access pull on
small tab labeled “OPEN”. Replace with a new 9-Volt battery.
Always remember to unplug your guitar cords from the pedal
to conserve battery life. Some battery drain may take place
when unit is plugged in (even if the unit is bypassed).
