Descriptions continued.........
LEVEL Control - This control determines the
amount of level (or volume) of the effect.
TONE Control - This control determines the
overall EQ of the effect.
9VDC Input - This input jack provides 9VDC
power to the pedal from the Rocktron DC
OnTap 9V power supply (sold seperately).
GAIN Control - This control determines the
amount of gain (or distortion) added to the
signal.
ON/OFF Leds - These LEDs shows if the pedal
is on or off. When the LED is lit the pedal is
on. When the LED is not lit the pedal is off.
BATTERY COMPARTMENT and COVER
- The 9V battery can be found in this
compartment.
1
2
3
4
5
6
