Descriptions continued.........
LEVEL Control - This control determines the
overall volume of the delay effect.
QUICK/EXTENDED Switch - This switch
allows selection between two delay times in
milliseconds. The QUICK delay is between 0ms
and 200ms. The EXTENDED delay is between
200ms and 400 ms. The actually delay time is
then adjusted using the TIME control knob.
9VDC Input - This input jack provides 9VDC
power to the pedal from the Rocktron DC OnTap
9V power supply (sold seperately).
REGEN Control - This control determines the
number of reptitions (regeneration) of the delay
effect.
TIME Control - This control determines the
length of the delay effect. This control is used in
conjction with the QUICK/EXTENDED Switch.
ON/OFF Leds - These LEDs shows if the pedal
is on or off. When the LED is lit the pedal is on.
When the LED is not lit the pedal is off.
