Rocktron Sacred Fire Compressor - Manual (Page 6)

Descriptions continued.........
GAIN Control - This control determines the amount of output level
(makeup gain) after the compression is applied.
THRESHOLD Control - This control determines the level at which
compression is performed.
9VDC Input - This input jack provides 9VDC power to the pedal from
the Rocktron DC OnTap 9V power supply (sold seperately).
SACRED FIRE Control - This control determines the amount of
compression that will be applied to the signal when the threshold has
been reached.
ON/OFF Led - This LED shows if the pedal is on or off. When the
LED is light the pedal is on. When the LED is not light the pedal is
off.
INPUT Jack - Using a standard 1/4” guitar cable, plug your guitar into
this jack.
FOOTSWITCH - Use this switch to turn on or off the pedal. The On/
Off Led will show you if the pedal is on or off.
OUTPUT Jack - This jack provides the output of the effect. Use a 1/4”
guitar cable to plug into the next effect or into a guitar amplifier.
