Rocktron Valve Charger - Manual (Page 6)

Descriptions continued.........
CHARGER Control - This control determines the amount of over-
drive. Turn right for more overdrive, turn left for less overdrive.
TONE Control -The control determines the amount of high EQ.
9VDC Input - This input jack provides 9VDC power to the pedal from
the Rocktron DC OnTap 9V power supply (sold seperately).
LEVEL Control - This control determines the overall output level of
the pedal.
ON/OFF Led - This LED shows if the pedal is on or off. When the
LED is light the pedal is on. When the LED is not light the pedal is
off.
INPUT Jack - Using a standard 1/4” guitar cable, plug your guitar into
this jack.
OUTPUT Jack - Using a standard 1/4” guitar cable you can plug in
another pedal from this jack or plug directly into your amplifier.
FOOTSWITCH - Use this switch to turn on or off the pedal. The On/
Off Led will show you if the pedal is on or off.
1
2
3
4
5
6
7
8
