Rocktron Rampage R80 DSP - Manual (Page 6)

AGX (Automatic Gain Expander)
Rocktron’s patented AGX system solves the long standing problem encountered by guitar players
when using high gain distortion. The AGX circuit expands the gain of the amplification circuit only
when required based on the input level. When no signal is present, the AGX circuit expands down
the amplification level to a point where hum and noise are dramatically reduced.
Power Output
Speakers
EQ Treble
Middle
Bass
Outputs: Line
Preamp
Headphone Output
Effects Loop
Channels
Effects
Scoop
Dimensions
Weight
Power Requirements
80 Watts
12” Velocity High Definition by Rocktron
Active Shelving
Active Bandpass
Active Shelving
1/4” jack
1/4” jack
1/4” jack
2 x 1/4” jack
Overdrive and Clean (Footswitchable)
Digital (Footswitchable)
Bandstop
20”H x 12” W x 18”D (600x390x550mm)
38.38 lbs. (19kg.)
100 Volts AC 50/60Hz or 117 Volts AC, 50/60Hz
or 220/240 Volts AC, 50/60Hz, as specified on chassis
R80DSP Specifications
