Chapter 2 Operation
2.1 On-screen Display Operation
LCD membrane
Membrane Switch Function
Power light
Green = On
Orange = Power saving
Power on / off LCD
Display the OSD menu
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button
for 5 seconds)
Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
Remark: All LED touch buttons in WHITE light.
1. The LED of Power touch button will flash continuously when there is no signal input.
2. All the LED touch buttons will automatically turn off after 10 minutes of idle status (except the Power).
3. Light up all membrane buttons, please press any button for 1 - 2 seconds (except the Power).
