12
Audio
Power
KVM
DVI-D HDMI
S-Video BNC
in - in - out
PC Video
■ Option excludes 1 x power cord and 1 x AC power adapter.
■ For dual slide 1U / 2U LCD console drawer, the user can only select one of the above four options.
5 Product Options
5-1 Port Options
5-2 DC Power Options
For DC power option :
DC Power
KVM
Model 12V 24V 48V
Input rating
Input voltage: 12-Volt 24-Volt 48-Volt
Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V
Input current
- No load
50 mA 50 mA 50 mA
- Full load 4950 mA 2450 mA 1220 mA
Output rating
Output voltage:
12-Volt 12-Volt 12-Volt
Output current: 4.16A 4.16A 4.16A
Efficiency 84% 85% 85%
■ HDMI (HDMI 1.1, CEA-861-D)
■ DVI-D (DVI-D TMDS single link)
■ AV (S-Video + Composite, BNC)
■ Audio (3.5mm audio jacks for audio in & out, and 2W + 2WW Speakers
