4.0 OPERATING INSTRUCTIONS
The instruction label from the top of the instrument is reprinted here in case it is ever defaced.
4
QX EB TCAT-2DF Rev 1 (Prtlw) 08/29/07
OFF/ON
POWER
SWITCH
FEEDBACK
SENSOR
AC OUTPUT FUSE
6.3A 250V Slo Blo
CONTROLLED
AC OUTPUT
TCAT-2DF
CONTROLLER
OPERATING INSTRUCTIONS
The TCAT-2 Controller parameters are set at the factory for for the specific load supplied with it. If the
TCAT-2 has not been so supplied, see the Operating Manual for adjustment of the control parameters
1. Connect the thermocouple sensor to the blue Feedback Sensor Socket on the rear panel and
position the sensor.
2. Connect the load (heating pad or blanket) to the Low Voltage 7-pinOutput Socket on the rear of
the controller or controlled AC output socket(s) 500W AC max.
3. Connect the controller power cord to a suitable AC outlet.
4. Turn on controller Power Switch (rear panel). Set position of Heat/Cool Switch depending on
control protocol (See manual for details.)
5. Set the control temperature:
a) Press Function Key. SP will appear on the
display.
b) Press UP or DOWN buttons and hold until
desired control temperature is reached.
c) Press Function key again to enter new
control temperature.
SPECIFICATIONS:
Operating Range: -128°C to +400°C
Resolution: 0.1°C
AC Input Voltage: 110-130VAC or 220-240VAC, 50 or 60Hz (see Operating Manual)
SPECIAL DISPLAY INDICATIONS:
Red lamp will be illuminated when power is being supplied to load.
VIEWING ANGLE
The two front feet can be flipped down to adjust the viewing angle. Rotate feet down and
towards the front until they lock in position. To return to original position, pull down slightly,
then rotate back.
Function Key
(Scroll)
UP
-14.9
DOWN
RUN Display
SET Display
PV
SP -15.9
Serial Number:
PHYSITEMP INSTRUMENTS INC
154 Huron Avenue
Clifton, NJ 07013 USA
Tel: 973-779-5577, Fax: 973-779-5954
www.physitemp.com
Made in USA
