The CG location is 74mm back from the leading edge of the wing. Install the
recommended fl ight battery with the end of the battery aligned with the rear
edge of the foam battery shelf. Make sure the fl ight battery is secured using
the hook and loop strap. It is easiest to balance the Focke-Wulf with the
aircraft inverted.
Aircraft CG and weight is based on a ParkZone 11.1V 2200mAh 25C battery
(PKZ1029) installed.
Center of Gravity (CG)
74mm
2.90 inches
back from the
leading edge of
the wing.
NOTICE: NEVER attempt to belly land your aircraft with the cannons installed or
damage to the aircraft may result.
1. For scale appearance, install the included cannons by press fi tting them
into the leading edge of the wing as shown.
Cannon Installation
Decal installation
Your aircraft is supplied with two small Iron crosses for the tail insignia, to be
applied as shown. For those desiring a more accurate tail insignia, other decals
are available separately (PKZ4930, not available in all territories).
1. Read this instruction manual thoroughly.
2. Remove and inspect the contents.
3. Charge the fl ight battery.
4. Fully assemble the model.
5. Install the fl ight battery in the aircraft (once it has been fully charged).
6. Bind the aircraft to your transmitter. 7. Make sure the linkages move freely.
8. Perform the Control Direction Test with the transmitter.
9. Adjust the fl ight controls and transmitter.
10. Perform a radio system Range Check.
11. Find a safe and open area.
12. Plan fl ight for fl ying fi eld conditions.
First Flight Preparation
