30
GTO Photo Beams
GTO Loop Detector
Mighty Mule
Push Button Control
According to
Application
According to
Application
Mighty Mule
Vehicle Sensor
Refer to Vehicle Sensor
manual for additional
connections.
Edge Sensor
ON 1 2 3 4 5 6 7 8 9
10 DIP
NO
COM
NC
V +
V –
LOOP
LOOP
LOOP
NOTE: Connections are for typical
applications. There may be additional
connection options for applications that
are not illustrated here.
2
1
1
1
3
1
4
Mighty Mule Keypad
3
4
5
1
1
2
1 2 ABC 3 DEF
4
GHI
5 JKL 6 MNO
7 PRS 8 TUV 9 WXY
0
7
6
1 2 3 4 5 6 7
RECEIVER
ALM
GTO RCVR.
WHT B
LU
BRN O
RG
RED BLK GRN
CO
M
GRN BLK RED
CY
CLE
SAFET
Y
EXIT
SHADO
W
OPEN EDGE CO
M
MASTER OPERATOR CONTROL INPUTS
CL
OSE
EDGE
Connecting Additional Devices
Although GTO strongly recommends the use of additional safety devices, we do not
endorse any specific brand names. Only use products that are certified and listed to be in
compliance with any applicable UL safety standards
(Underwriters Laboratories) and national and regional safety codes.
Call GTO Sales at 1-800-543-4283 for information on compatible products for your specific
application
The Mighty Mule 600 will ONLY accept accessory devices with normally open dry contact output.
