Marsh Sound Design HT 750,3 Channel Power Amplifier - Manual (Page 14)

14
Marsh Sound Design
MSD-HT750 Specifications
Power Output (All channel driven) 150 W(Rms) @8 ohms 20 Hz-20 kHz
250 W(Rms) @4 ohms 20 Hz-20 kHz
Power Output - Peak (Burst 1 cycle sine, interval = 10)
205 W @5 ohms
385 W @4 ohms
Total Harmonic Distortion (THD)+Noise < 0.02% @20 Hz-20 kHz at 150W, 8 ohms
< 0.04% @20 Hz-20 kHz at 250W, 4 ohms
Frequency response 20 Hz-20 kHz @0.2 dB
-1 dB @70 kHz
Signal to Noise ratio (A-Weighted) > 100 dB (Unbalance)
> 90 dB (Balance)
Crosstalk > 60 dB, 20 Hz-20 kHz
Damping Factor 230 @8 ohms and 110 @4 ohms
Dynamic Headroom 1.35 dB
Input Impedance 50 k ohms (Balance) at 1 kHz
40 k ohms (Unbalance) at 1 kHz
Input Sensitivity 1.28 V @8 ohms,150W
Bandwidth 130 kHz @1W, 8 ohms Load
Net Weight 76.16 lbs (34 kgs).
Shipping Weight 85.12 lbs (38 kgs).
SPECIFICATIONS
