Marsh 10
The unit is always in standby mode when the AC power cord is plugged into AC wall outlet. The power LED
will be in dimly BLUE color. The preamplifier does not operate in this state. But the internal circuitry always
has power applied to it all the time.
1. POWER Pressing the POWER button to turn the unit into operation mode. The power
LED will appear brightly BLUE. The unit is fully functioning in this mode.
Press POWER button again to standby mode. The LED will be dimmed blue in this
mode.
2. TAPE Press the TAPE button once to select TAPE input as the source. The green LED will
be lit while in TAPE mode. Press TAPE button again to deactivate TAPE mode.
3. SELECTOR Turn the selector knob to the desired source input.
.
4. BALANCE Turn the balance level knob to adjust the sound balance between two speakers. Leave
it in the center position to give equal output on both channels.
Sometimes in unequal source recording, you may need to adjust the balance level to
get a balanced stereo sound. If the sound weaker on left side, move the knob to left
until you hear equal sound from speakers and vice versa.
5. VOLUME Adjust the output level.
Remark: The MSD-P2000 has an on-off digital control signal (REMOTE) to turn the power amplifier, with
remote turn-on capability, ON/OFF with the preamplifier.
Functions
BALANCE VOLUME
TAPE POWER
DVD VIDEO
TUNER
CD
LINE1
LINE2
Marsh
H R L A IGH ESOLUTION INE MPLIFIER
Marsh Sound Design MSD- 2000 P
5 4 3 2 1
