VariMax: ORIENTATION REQUIREMENTS

Pump Orientation Image

Pump Orientation Run Condition

Note:
Attachment hoses should be fixed so as to not create an axial push/pull load on the pump.
The pump should not be at the highest point within the coolant circuit to prevent air entrapment

Pump runs normally in these positions

Pump

DOES NOT

run normally in these positions

NOT GOOD
