LEHR 2.5 HP 4-STROKE - Manual (Page 26)

LEHR | ALL RIGHTS RESERVED 2012-2013 24
SPECIFICATIONS
MODEL LP 2.5S
ENGINE TYPE WATER COOLED 4-CYCLE
DISPLACEMENT 72.0 CC
*ALL SPECIFICATIONS ARE BASED ON THE LATEST PRODUCT INFORMATION AT THE TIME OF PRINTING.
WE RESERVE THE RIGHT TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE.
BORE X STROKE 54 mm X 31.5 mm
GEAR RATIO 2.08
GEAR SHIFT F – N
TRANSOM HEIGHT 15” (381 mm)
MAX OPERATING R.P.M. 3000 - 3500 R. P.M.
IDLE SPEED 2000 R. P.M.
IGNITION TYPE ELECTRONIC
IGNITION SWITCH TETHER
VALVE CLEARANCE IN and EX (COLD)
SPARK PLUG GAP 0.020-0.024 INCH (0.5-0.6 mm)
LUBRICATION
CRANKCASE OIL CAPACITY 0.37 US qt (0.35L)
FUEL
STARTER PULL CHORD AUTO REWIND
.003 - .005 in (0.08-0.12mm)
PROPANE
4 STROKE 10W-30
SPARK PLUG TORQUE SPEC 18.4 ft•lb (25.0 N•m)
GEAR OIL CAPACITY 2.54 fl oz. (0.075L)
SPARK PLUG TYPE NGK BR 6 H8
POWER 2.5 hp (1.8 kW)
WEIGHT 37.9 lbs (17.2 kg)
