WIRING
DIAGRAM
SPECIFICATIONS
1
3
2
Fan
Switch
7 5
B A
Motor
Relay
White
Red Orange
Orange
Red
Black
White
Black
White
Blue
Blue White
Black Black
Thermostat B
R
Flame-out
Control
Reset
Button
Red
Yellow
Yellow
White
Solenoid
Valve
White
Terminal
Board Terminal
Board
Ignitor
White
Spark
Plug
Photocell
Brown
Blue
Green/Yellow
Plug
220/240V~
50HZ
Yellow
White
Green/Yellow
Black Black
Start Capacitor
Purple
Purple
HIGH PRESSURE AIR GAGE - M4574
Special tool to check pump pressure
ACCESSORY Purchase this heater accessory from you local dealer.
Output Rating (Btu/Hr) 340,000
Fuel Use Only Kerosene or No. 1 Fuel Oil
Fuel Tank Capacity (U.S. Gal./Liters) 30/113.6
Fuel Consumption
(Gal. Per Hr/Liter Per Hr) 2.5/9.5
Electric Requirements 220/240V, 50 Hz
Amperage (Normal Run) 5
Motor RPM 2850
Fuel Pump Pressure (PSI) 100
Spark Plug Gap .055" (1.4 mm)
Weight (approx. lbs./kilograms) Dry (net) 180/82
With Full Fuel Tank 390/177
