Specifications.
GENERATOR
Pulse rate 1Hz
Frequency spectrum, electrical 1Hz to 0KHz
Frequency spectrum, acoustic 00Hz to KHz
Output level, electrical 0 to 1V (Acoustic level is fixed)
Output load impedance >1KΩ
Output source impedance 1KΩ
Power 9V PP battery (= approx 0 hours)
Power drain 10mA
RECEIVER
Frequency spectrum, electrical 1Hz to 0KHz
Frequency spectrum, acoustic 10Hz to 1KHz
Input impedance (Mic) 1KΩ
Input impedance (Line) 10KΩ
Input level (Mic) 10mV - 1V
Input level (Line) 0.V to 0V
Output level 0V to 1V
Power 9V PP battery (= approx 0 hours)
Power drain 10mA
PHYSICAL CHARACTERISTICS (each box)
Dimensions 10mm W x 80mm D x 0mm H
Weight 0. Kg
Shipping weight 0. Kg
Operating temperature 0 - 0 deg C
Storage temperature -0 - + deg C
Warranty.
Your LA Audio PC90 has been manufactured to a high standard using quality
components. If correctly installed and operated the unit should give years of
problem free operation.
However in the event of a defect in material or workmanship causing failure of
the unit within 1 year of the date of original purchase we will agree to repair, or
at our discretion replace, any defective item without charge for labour or parts.
To receive service under this warranty it is necessary to return the unit to an
LA Audio authorised service centre or to the factory with a dated receipt as
proof of purchase. After repair the unit will be returned to you free of charge.
Limitations:
This warranty does not cover damage resulting from accident or misuse.
The warranty is void unless repairs are carried out by an authorised service
centre. The warranty is void if the unit has been modified other than at the
manufacturers instruction. The warranty does not cover components which
have a limited life, and which are expected to be periodically replaced for
optimal performance. We do not warrant that the unit shall operate in any way
other than as described in this manual.
