PARTS LIST
VI33PRA
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 23 of this manual.
REMOTE READY MODEL
VI33PRA
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
102785-03
Log, Golden Oak
1
2
103778-01
ODS Pilot (Propane/LP)
1
3
098249-01
ODS Nut
2
4
099387-07
Pilot Tube
1
5
104229-04
Burner Outlet Tube
1
6
102843-01
Burner Clip
1
7
099056-19
Burner Orifice Injector
1
8
102772-01
Burner
2
9
M11084-38
Screw, #8 x .38
2
10
104236-03CK
Painted Base Assy
1
11
M12461-26
Screw, #10 x .32
4
12
104238-04CK
Firebox Bottom
1
13
103284-03
Wiring Harness
1
14
098265-02
Elbow, Male
1
15
103782-01
Valve Bracket
1
16
103781-02
Gas Control Valve
1
17
098271-03
Ignitor Cable
1
18
102445-01
Piezo Ignitor
1
19
098304-01
Screw
7
20
099998-01
Switch
1
21
104241-01
Remote Switch Bracket
1
22
103587-01CK
Switch Plate
1
23
097809-02
Male Connector
1
24
101628-03
Flexible Connector (Hose)
1
25
M50104-02
Bushing
1
26
M11084-26
Screw, #10 x .38
4
29
103977-02
Button Plug 3/4"
1
30
103977-01
Button Plug 5/8"
1
PARTS AVAILABLE — NOT SHOWN
103877-01
Lighting Instruction Plate
1
100563-01
Warning Plate
1
