Konig Electronic COB Mobile LED Floodlight 10 W 700 Lumen UK plug - Manual (Page 5)

55
English
Technical data
KNLEDFLMB10W
KNLEDFLMBUK10W
KNLEDFLMB20W
KNLEDFLMBUK20W
Input voltage 12 V DC 12 V DC
Frequency 50 - 60 Hz 50 - 60 Hz
Wattage 10 W 20 W
Ingress protection class
(IP code)
IP65 IP65
Luminous flux 700 lm 1400 lm
Colour rendering index (CRI) > 70 > 70
Colour temperature
5500 - 6500 K
(Daylight white)
5500 - 6500 K
(Daylight white)
Beam angle 120° 120°
Charging duration 7 hours 7 hours
Operating hours
4 hours
4400 mAh / 7.4 V
4 hours
8800 mAh / 7.4 V
Ambient temperature -20 °C ~ 40 °C -20 °C ~ 40 °C
Dimensions (LxWxH) 145x170x215 mm 215x186x270 mm
Weight 900 g 1750 g
Warranty
Floodlight
Battery
2 years
1 year
2 years
1 year
Safety
General safety
• Read the manual carefully before use. Keep the
manual for future reference.
• Only use the device for its intended purposes.
Do not use the device for other purposes than
described in the manual.
• Do not use the device if any part is damaged or
defective. If the device is damaged or defective,
replace the device immediately.
• The device shall not be used by children without
the supervision of an adult. Children shall not
play with the device.
• Do not modify the device in any way.
• Do not expose the device to water or moisture.
• Keep the device away from heat sources.
• Do not block the ventilation openings.
• Do not look directly into the LED lamp.
• Observe the minimum distance between the
lamp and the surface being illuminated. The
minimum distance is 2 metres.
Electrical safety
• To reduce risk of electric shock, this product
should only be opened by an authorized
technician when service is required.
• Disconnect the product from the mains and
other equipment if a problem should occur.
Warranty
Any changes and/or modifications to the product
will void the warranty. We cannot accept any
liability for damage caused by incorrect use of the
product.
Disposal
• The product is designated for separate
collection at an appropriate collection point.
Do not dispose of the product with household
waste.
• For more information, contact the retailer or the
local authority responsible for waste
management.
Documentation
The product has been manufactured and supplied
in compliance with all relevant regulations and
directives, valid for all member states of the
European Union. The product complies with all
applicable specifications and regulations in the
country of sales.
Formal documentation is available upon request.
The formal documentation includes, but is not
limited to the Declaration of Conformity, the
Material Safety Data Sheet and the product test
report.
Disclaimer
Designs and specifications are subject to change
without notice. All logos, brands and product
names are trademarks or registered trademarks of
their respective holders and are hereby recognized
as such.
