Konig Electronic IR remote control extender User Manual
Page 21
21
Bak:
DC 12 V,
Strömförsörjning
IR förlängningskabel med
3 IR ögon
IR mottagningsgivare
Applikation 1:
1. Anslut IR förlängningskabeln till den
infraröda mottagaren som visas på bilden.
2. Placera IR ögat precis framför IR givaren för
apparaten.
3. Anslut strömmen.
Applikation 2:
1. Anslut IR förlängningskabel och IR
mottagnings givare till den infraröda
mottagaren som visas på bilden.
2. Placera IR ögat precis framför IR
givaren för apparaten.
3. Anslut strömmen.
