Konig Electronic 8 port composite audio/video switch User Manual
Page 24
24
8 kanály
Číslo Popis
Funkce
1 Tlačítko Přepínání signálu
2 Cinch-výstup Výstup
audia/videa
3 Cinch-vstup Vstup
audia/videa
V. Instalace:
Zapojení 4-kanálového kompozitního AV přepínače
Zapojení 8-kanálového kompozitního AV přepínače
A. VCD/DVD přehrávač nebo zařízení s cinch
B. Vstupní signál
C. Výstupní signál
