Step 1: Base
A. Snap the
two feet
on one
end of
the base
into its
4-way
fitting.
B. Do the
same
with the
two feet
on the
other
end of
the base.
C. Snap the two long parts of the base
together, making sure the lock button is
secure in the hole.
Step 2: Single Upright
A. Snap the single upright piece into
either one of the two 4-way fittings on
the base.
JUGS Quick-Snap
®
L-Shaped Screen
Assembly Instructions
Take the frame sections and netting from
your bag and separate them. Then follow
these five easy steps.
Step 3: Middle Section
A. Snap the pieces of the middle
section together.
B. Snap the shorter bar—upright—into
the other 4-way fitting on the base.
Top Section
Single
Upright
Middle Section
Base
lock
button
