2. Installation of Receiver and Servos
After connecting the receiver and servos as below illustration, turn on the power to
the transmitter first then turn the receiver on. (Always turn the transmitter ON first
and OFF last.) This will prevent the receiver from picking up stray signals and
going out of control. Now, move the controls to see if the servos are moving properly.
If not, check your wiring or crystals if the servos do not move at all.
6
STANDARD VERSION
FEATHER VERSION
(not available in USA)
#54402 AAA size RX Battery box
#54403 MICRO S/W HARNESS
#54402 AAA size RX Battery box
#54403 MICRO S/W HARNESS
7.2V -8.4V Nicad
Electric Glider only(Not included)
7.2V -8.4V Nicad
Electric Glider only(Not included)
