17
Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you
are completely satisfied with the contents of your kit. However, we do ask you to check all the parts (referring to the Parts List)
before you start construction, as we cannot exchange components which you have already modified. If you find any part is not
acceptable, we will readily correct or exchange it once we have examined it. Just send the component to our Model Department;
please be sure to include the purchase receipt and a brief description of the fault.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in
terms of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we
cannot entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and operating them safely
requires a certain level of technical competence and manual skill, together with discipline and a responsible attitude at the
flying field. Errors and carelessness in building and flying the model can result in serious personal injury and damage to
property. Since we, as manufacturers, have no control over the construction, maintenance and operation of our products,
we are obliged to take this opportunity to point out these hazards and to emphasise your personal responsibility.
Additional items required for the EasyCub:
Airborne radio control components:
MULTIPLEX RX-7-Synth IPD receiver
35 MHz A band Order No. 5 5880
alternatively: 40 / 41 MHz band Order No. 5 5882
or MULTIPLEX RX-6-Synth light 35 MHz A / B-band Order No. 5 5876
2 x MULTIPLEX Tiny S servo elevator, rudder Order No. 6 5121
or 2 x MULTIPLEX Tiny MG servo elevator, rudder Order No. 6 5122
Power set:
MULTIPLEX EasyCub power set
Order No. 33 2637
Motor: Himax C 2816-1220; speed controller: BL 27 II; 10 x 5” propeller, propeller driver
Flight battery:
MULTIPLEX Li-Batt eco 2/1-2000 flight battery
Order No. 15 7230
or MULTIPLEX Li-Batt BX 2/1-2100 flight battery Order No. 15 7130
Tools:
Scissors, balsa knife, combination pliers, screwdriver.
Specification:
Wingspan:
1400 mm
Fuselage length: 980 mm
All-up weight with Li-Batt BX 2/1-2100 approx.: 850 g
Wing area: 36.5 dm²
Wing loading (FAI) approx.: 23 g/dm²
RC functions: Rudder, elevator, throttle
Note: please remove the illustration pages from the centre of the instructions.
Important note
This model is not made of styrofoam™, and it is not possible to glue the material using white glue, polyurethane or
epoxy; these adhesives only produce a superficial bond which simply gives way when stressed. Please use medium-
viscosity cyano-acrylate glue exclusively, preferably our Zacki-ELAPOR®, # 59 2727 - the cyano glue optimised
specifically for ELAPOR® particle foam.
If you use Zacki-ELAPOR® you will find that you do not need cyano kicker or activator for most joints. However, if you
wish to use a different adhesive, and are therefore obliged to use kicker / activator spray, we recommend that you
apply the material in the open air to avoid health problems.
Please take care when working with any type of cyano-acrylate (“cyano”, “CA”) adhesive, as they can cure in
seconds. Don’t allow the glue to contact your fingers or any other part of your body. Always wear goggles to protect
your eyes!
Keep out of the reach of children!
# 21 4235
GB
