C-BOX 150
2
2.6 TYPICAL
LAYOUTS
2.6.1
1000, 2000A/N, 4000 Family Scanners
For 1000, 2000A/N and 4000 scanner families which operate in a point-to-point
single scanner configuration, a typical layout is shown below and the C-BOX 150 is
connected as follows.
Laptop
Host
Scanner
1
2
3
1
2
3
Main serial interface
Auxiliary serial interface (Local Echo)
External Trigger (for On-Line mode)
PWR supply
C-BOX 150
Figure 17 – Typical point-to-point scanner Layout
20
