4670PE31GDT_setup_sheet.xls
SKU
SYSTEM BUILDER SKU
PRODUCT
PRODUCT SHORT INTERFACE PCI Express x16
DESCRIPTION GPU HD4670
CORE CLOCK 750 Mhz
MEMORY CLOCK 900 Mhz
MEMORY CONFIGURATION 64Mx16
MEMORY TYPE GDDR3
MEMORY BANDWIDTH 32 GB/sec
MEMORY SIZE 1024MB
MEMORY CONTROLLER INTERFACE 128-Bit
DUAL MONITOR 2-Dual-Link DVI, S-Video
DUAL LINK DVI Hydravision 4
EXTERNAL POWER REQUIREMENT 6-pin molex adapter
SYSTEM REQUIREMENT CPU
Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
SYSTEM REQUIREMENT CPU SPEED 2.0 Ghz or faster
SYSTEM REQUIREMENT MEMORY 1024MB
SYSTEM REQUIREMENT POWER SUPPLY 400 Watt or higher
SYSTEM REQUIREMENT SPECIAL INSTRUCTIONS None
SYSTEM REQUIREMENT HARD DISK 480MB available hard disk space
SYSTEM REQUIREMENT BUS PCI Express x16
SYSTEM REQUIREMENT STANDARD SLOT
SOLUTION
SINGLE
SYSTEM REQUIREMENT CHASSIS N/A
SYSTEM REQUIREMENT MONITOR
Digital flat-panel (DFP) displays or DVI-I Compatible or
digital CRT display or High-resolution VGA monitor
SYSTEM REQUIREMENT INTERNET ACCESS N/A
SYSTEM REQUIREMENT USB NO
SYSTEM REQUIREMENT CD DVD YES
SYSTEM REQUIREMENT OS WINXP YES
SYSTEM REQUIREMENT OS WINXP64 YES
SYSTEM REQUIREMENT OS WINVISTA32 YES
SYSTEM REQUIREMENT OS WINVISTA64 YES
PRODUCT DIMENSIONS
RETAIL BOX DIMENSIONS
6.6 X 4.4 X .7 inches
11.75 X 9.5 X 3
Unified Video Decoder (UVD 2) for Blu-ray and HD DVD
ATI PowerPlay energy conserving technology
OpenGL 2.0 Support
SYSTEM REQUIREMENT
OPERATING SYSTEM
55nm process technology
ATI Avivo HD Video and Display Technology
Game Physics processing capability
Up to 24X Custom Filter Anti-Aliasing
Built-in HDMI with Multi-channel 7.1 surround audio
On board HDMI connector (with adapter)
PRODUCT DETAILED DESCRIPTION
Loaded with the latest features, ATI RadeonTM HD 4600 Series graphics cards deliver a level of gaming
performance previously only found in high-end graphics cards. Redefine the way you play HD games and enjoy
unprecedented levels of graphics realism powered by 320 stream processing units, up to 1GB of memory and
support for Microsoft DirectX®10.1 games. Upgrade your graphics card and watch Blu-ray movies and play HD
content with incredible visual fidelity1. These graphics cards do it all with break-through energy efficiency,
eliminating the need for an external power connection and making them easy to install.
PRODUCT FEATURES Superscale unified shader architecture
PCI Express x16 2.0 support
320 stream processing units
Direct X 10.1 / Shader Model 4.1
ATI Crossfire X Multi-GPU Support for highly scalable performance
Up to four GPU support with an AMD 790FX based motherboard
High-speed 128-bit-HDR (High Dynamic Range) rendering
DIAMOND MULTIMEDIA Product Setup Sheet
DATE : September 5, 2008 - 5:08 pm
4670PE31GDT
Diamond Radeon HD 4670 GDDR3 1GB Video Card
Page 1 of 2
