19 104276
OWNER’S MANUAL
PARTS LIST
CGN10RLA
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 16 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 099467-07 Front Panel Assembly 1
3 099318-03 Grill Guard 1
4 101108-01 Grill Guard Clip 2
5 099469-02 Reflector Assembly 1
6 M15823-37 Screw Hex #8 x 1/4" 10
7 503329 ODS/Pilot Assembly 1
7-1 098514-01 Thermocouple 1
7-2 098594-01 Ignitor Electrode 1
8 099884-02 Burner Assembly 1
9 099056-06 Injector 2
10 099390-02 Tubing - Valve to plaque A 1
11 099387-05 Pilot Tubing - Valve to pilot 1
12 099392-01 Tubing - Valve to plaque B 1
13 099391-02 Tubing - Regulator to valve 1
14 100432-01 Control Valve 1
15 099468-17 Cabinet Assembly 1
16 099415-14 Gas Regulator 1
17 098303-02 Screw, #6 x 5/16" 2
18 098508-01 Valve Retainer Nut 1
19 099393-02 Control Knob 1
20 M11084-26 Screw, #10 x 3/8" 2
21 099818-01 Internal Tooth Washer 1
22 097159-04 Piezo Ignitor 1
23 098271-03 Ignitor Cable 1
PARTS AVAILABLE - NOT SHOWN
099395-07 Control Position Label 1
100642-02 Assembly, Hardware 1
