3

4

Installation

Hanger

Wall mount

Ceiling mount

Without mounting bracket installation

With mounting bracket installation(optional)

Wood material installation

Concrete material installation

Hidden installation

Wall mount

Ceiling mount

Ceiling Mount

Using a tape measure, measure the distance between the two keyholes on the

casing (figure 1).

According

to the measurement, use the drill to drill identical holes of the appropriate size on the

ceiling

(use a smaller

drill bit than the actual screws) and ensure that it is level (f igure 2 & 3). Screw in the hook

screws (not provided), and lift the screen into the hook screws to hang (figure 4). To ensure that

the

screen is level, use a level to

check (figure 5).

A

A

1

2

3

4

5

Wall mount

Ceiling mount

Motor adjusting slot

Picture 1

Picture 2

Picture 3

2. Remote control (Please see section on Remote Control)

Grandview projection screens are controlled by a manual switch or an remote control.

1.Manual switch

a.T

b.Connect to a power source (Please make sure it is the right voltage)

c.

; it will come down slowly. When it is all the way down, it

will stop automatically.

d.

; it will go up into the meta l casing. When it is all the way up,

it will sto p automatically.

e.Turn the switch to position to stop any time the screen.

ear off the glue cloth fixed on the bottom rod, ensure the bottom rod is not stuck by the casing.

Turn the switch to position

to lower the screen

Turn the switch to position

to retract the screen

Operation

Attention:
> Please make sure there is no dust or dirt on the fabric surface before rolling it back to the casing
> The recommened working time is less than 50 seconds. The motor will enter overheating protection
status and stop working for every continuous 4 minuters operation, user would need to wait for a while
until the motor cool down before operating again.
> There is no lube needed for the motor. Please be noticed that the appropriate setting is optimized which
requires no further adjustment, please consult the after sales team before adjusting the limits.
