108660-01D
25
25
For more information, visit www.desatech.com For more information, visit www.desatech.com
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 108406-01 Insulation Pan 1
2 108403-01 Fireplace Top Assembly 1
3 108405-01 Fireplace Surround 1
4 108425-01 Air Rod Retainer 1
5 108423-01 Panel Closure 2
6 108409-01 Firebox Bottom 1
7 ** Firebox Surround 1
8 108411-01 Air Separator 1
9 108434-01 Left Refractory, Std. Brick (B Models) 1
10 108432-01 Right Refractory, Std. Brick (B Models) 1
11 108430-01 Rear Refractory, Std. Brick (B Models) 1
12 108428-01 Bottom Front Refractory, Std. Brick 1
13 108426-01 Bottom Rear Refractory, Std. Brick 1
14 106683-01 Firebox Support Leg 2
15 24353 Box Assembly 1
16 108701-01 Screen Rod 2
17 108407-01 Firebox Top Assembly 1
18 11165 Screw, #10x5/8 Mod. Tr. Blk. Ox 2
19 106703-02 Damper Door Assembly 1
20 108401-01 Firebox Face 1
21 108412-01 Smoke Deflector 1
22 ** Fireplace Top Insulation 1
23 109040-01 Grate Assembly 1
24 108712-03 Burner Assembly 1
24-1 107742-03 Burner Pan 1
24-2 109037-01 Burner Tube 1
24-3 107748-01 Burner Bracket 1
24-4 107985-01 Pilot Shield 1
24-5 901681-01 Burner Clamp 1
24-6 11209 Nut, #10-24 1
24-7 11147 Screw, #10-24x1/2 1
24-8 901066-01 Brass Air Mixer (Natural Gas) 1
901066-02 Brass Air Mixer (Propane/LP) 1
24-9 901064-11 Injector (Natural Gas) 1
901065-09 Injector (Propane/LP) 1
PARTS LIST
P325(B) AND VP325(B) MODELS
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 18 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
P325(B) and VP325(B) Models
24-10 108084-01 Pilot (Natural Gas) 1
24-11 108085-02 Pilot Orifice (Propane/LP) 1
24-12 11102 Screw, #8-32x3/8 2
25 14512 Gas Control Valve (Natural Gas) 1
14513 Gas Control Valve (Propane/LP) 1
26 107741-02 Valve Bracket 1
27 14261 Piezo Ignitor 1
28 108368-01 3/8" Flex Line 1
29 11107 Screw, #10-32 x 1/4 PPH 4
30 108005-04 Wire Harness 1
31 11418 Push-On Nut 2
32 108440-01 Screen 2
33 14123 Strain Relief 1
34 14574 Limit Switch 1
35 22912 Draft Diverter 1
36 22084 Brick Liner Retainer 2
37 20042 Air Kit Cover 1
38 20088 Door Stop 1
39 20089 Pivot Clip 2
40 20090 Spring Clip 2
41 21171 Gas Knockout Cover 4
42 108652-01 Gas Conduit Assy, Left 1
43 108654-01 Gas Conduit Assy, Right 1
44 20280 Top Spacer 4
45 108415-01 Starter Pipe Collar 1
46 108417-01 5" Collar 1
47 108769-03 Extension Deflector 2
48 14253 Flexible Supply Line w/ Shutoff Valve 1
PARTS AVAILABLE NOT SHOWN
901155-01 Vermiculite Bag 1
901156-01 Pan Material 1
901157-01 Lava Rock 1
22180 Wall Switch Kit 1
**Not a field replaceable part.
