18
Replacement Parts List
Item Description
cerelm Ceramic element kit w/gasket
burnl Left burner housing
burnr Right burner housing (Elite I & II)
scrnl Left burner screen
scrnr Right burner screen (Elite I & II)
bcv Burner control valve
pcv Pilot control valve
bck Burner control knob
pck Pilot control knob
ign Ignitor w/knob
cgrid Cooking grid ea. (Specify Model)
dpan Drip Pan (Specify Model)
hndl Hood Handle (Specify Model)
wrack Warming rack (Specify Model)
orinat Natural orifice
orilp LP orifice
regnat Natural regulator
reglp LP regulator w/hose
TROUBLESHOOTING
PROBLEM PROBABLE CAUSE REMEDY
Pilot will not light A. Lack of gas A. Purge air in gas line.
when rotary ignitor B. Defective ignitor Fill gas cylinder
is turned C. Loose ignitor wire B. Replace ignitor
D. Pilot orifice obstruction C. Re-attach ignitor wire
D. Remove & clean pilot orifice.
At high setting burner A. Lack of gas A. Adjust regulator, clear
output is too low. Burner B. Damaged burner element orifice.
rumbles or flutters blue B. Replace burner element.
flame at surface.
At low setting burner A. Low heat setting is A. Adjust low heat setting.
output is too high adjusted too high
