10 Replacement Parts
Key No Part No Description G.C. Part No.
Diagram 10.1
Please quote the name of the appliance and its serial number, found on the data label on the right hand side of the control box, after
removal of the cover.
1 429549 Multifunctional control 312 926
2 208040 “O” ring - gas valve 334 592
3 203009 Injector 355 540
4 K2674 Thermocouple 390 894
5 K3580 Clip - thermocouple 390 983
6 203416 Pilot burner 381 793
7 900500 Spark electrode 381 733
8 WW4617 Ignition lead 312 997
9 202519 Thermostat 381 798
10 204687 Control knob
11 202713 Piezo unit
12 801236 Mica window and foil gasket
13 203350 Solenoid
14 800756 Safety device 278 470
Because of our constant endeavour for improvement, details may vary slightly from those shown in these instructions.
8057
13
9
10
7
5
12
6
2
4
3
1
8
11
14
