TECHNICAL DATA BROCHURE
Model 3301

IMPORTANT - READ OPERATOR'S MANUAL BEFORE OPERATING OR MAKING ADJUSTMENTS

SEAT ADJUSTMENT

1. Pull or lift body retention latch P/N 3954

from transaxle backing plate, raise and
push body and seat assembly forward.

2. Loosen four seat bolts P/N 3006 and

slide seat forward or backward to
desired position.

3. Re-tighten bolts. DO NOT operate

mower without seat retention bolts
properly tightened.

4. Close upper body and push retention

latch P/N 3954 over transaxle backing
plate.
