Glow-worm BBU 54/4 - Manual (Page 13)

13 2000225024C
Diagram 4.7
9393
Diagram 4.8
9387 GAS SERVICE
COCK (OFF)
No. 8 3/8 in.
SCREWS
REAR
SOCKET
FRONT
No. 8 1/2 in.
SCREWS
Fully fit No. 8 3/8 in.
screw into rear of
socket. Centralise
flexible flue liner
using the two
No. 8 1/2 in.
screws provided.
(Left hand water connection shown)
4 Installation
Diagram 4.9
9584
COMBUSTION
CHAMBER SCREW (4)
GAS
MANIFOLD
SCREW
Diagram 4.6
10260
SILICONE
TUBE
TUBING NUT
SENSING
TUBE
Diagram 4.10
BLANKING
PLATE
SECURING
SCREW
COMBUSTION
CHAMBER
10112
LOCATING
NIB
SENSING TUBE
SECURING
BRACKET
SECURING
SCREW
SENSING
TUBE
FLUE
BLOCKAGE
SAFETY
DEVICE
