—.Product.Guide.103.1.—.D:9
www.GeneralLock.com
Opening. . Dim..A. Dim..B
To.120º. . 8-3/4”. 3-3/4”
120º.and.wider. 11-1/4”. 1-3/4”
CL
12”
B
5-1/2”
3/4”
4-1/4”
Hinge
Jamb A
CL
speCifiCations:
.
Closer.for.interior.and.exterior.door.shall.be.needle-bearing.type.with.a.cast.aluminum.body..Closer.
shall.be.non-handed.to.permit.installation.on.either.side.of.the.door..Closer.shall.be.supplied.with.a.
standard.shoe.and.soffit.plate.to.allow.standard,.top-jamb,.or.parallel.installation..Closer.shall.contain.
hydraulic.fluid.that.is.non-gumming.and.non-freezing..Door.closer.shall.have.two.separate,.adjustable.
regulating.valves.to.control.sweeping.and.latching.speeds..Closer.shall.come.standard.with.backcheck.
feature..Closer.shall.fit.into.hole.patterns.12”.in.width.(two.holes.on.each.end).and.be.supplied.with.
machine.screw.and.sex.nuts.and.bolts..Closer.shall.be.ANSI.156.4.Grade.1.and.UL.Listed.for.use.on.
labeled.fire.doors..Closer.shall.be.available.with.slim.or.full-size.covers.
C7000 series door Closer installation
Parallel.Arm.Installation.and.Specifications
parallel arm installation:
.
Parallel.arm.application.is.the.least.power.efficient..It.provides.approximately.25%.less.power.than.
regular.arm..It.is.installed.on.the.frame.stop.(push).side.of.the.door..Since.it.is.parallel.with.the.
door,.it.is.chosen.for.appearances.and.is.least.susceptible.to.vandalism,.making.it.a.popular.choice.
in.schools..Parallel.arm.applications.require.at.least.4-1/2”.from.the.top.of.the.door.to.the.bottom.
mounting.point.of.the.door.closer,.or.else.a.drop.plate.must.be.used.
