OWNER’S MANUAL
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 17 of this manual.
PARTS LIST
CGP10TA
CGP10TLA
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
098304-01
Screw, #10 x 3/8"
2
2
099467-02
Front Panel Assembly (CGP10TA)
1
099467-07
Front Panel Assembly (CGP10TLA)
1
3
099318-04
Grill Guard
1
4
101108-01
Grill Guard Clip
2
5
102017-02
Bottom Glass Retainer
1
6
098260-11
Glass Panel
1
7
098532-06AA Top Glass Retainer
1
8
M11084-38
Screw, #8 x 3/8"
8
9
098352-03BR Deflector Unit
1
10
098271-03
Ignitor Cable
1
11
098249-01
Nut, M5
2
12
099059-03
ODS/Pilot Assembly
1
12-1 098514-01
Thermocouple
1
12-2 098594-01
Ignitor Electrode
1
13
104263-01
Burner
1
14
099387-11
Pilot Tubing
1
15
104259-06
Injector, 1 Piece
1
16
NJF 8C
Hex Nut
1
17
099415-13
Pressure Regulator
1
18
104261-01
Burner Tubing
1
19
104264-01
Regulator Tubing
1
20
098522-18
Thermostat Gas Valve
1
21
102571-06
Cabinet Assembly (CGP10TA)
1
102571-05
Cabinet Assembly (CGP10TLA)
1
22
097159-04
Piezo Ignitor
1
23
099553-01
Pilot Shield
1
24
098303-02
Screw, #6 x 5/16"
2
PARTS AVAILABLE - NOT SHOWN
102471-01
Control Position Label
1
100642-02
Assembly, Hardware
1
