4.0 Operation of the EX-5130-IS
It is best to have the EX-5130-IS transmitters powered up and operational for 24 hours before applying calibration or
test gas to them.
When the EX-5130-IS transmitter is first powered up, it goes through a series of momentary screens, which identify
the instrument model number, serial number and software revision. After all of the momentary screens have been
displayed, the instrument arrives at the Main Gas Display showing the gas concentration and unit of measurement.
Depending on transmitter configuration and calibration condition, the furthest right character in the display may flash a
letter indicating the instrument status. See the Section 4.1.2 below.
4.1 Start up
Typical Start Up
When power is supplied to the EX-5130-IS , the S/T will display the following sequence of information:
N OTE : Software revision may cause variations of display output.
Example of Display Function
The instrument: Model EX-5130-IS
Note Toxic is not displayed
The instrument: Serial Number
The instrument: Software Revision
IF the right most character is a flashing W The instrument is in Warm-up mode
This should last about 1 minute
The Signal Output is held at 4mA during warm-up
For Toxic Gas
The instrument: Normal Display Mode
Measurement of target Gas
IF the right most character is a flashing C, F, P or R See Section 4.1.2
EX-5130
77-1256
S/W X.X
0ppm
0ppmW
