ENG-97D S TAND -A LONE ENMET Corporation
2
2.0 Features
See figures 1 and 1A.
Feature Description
Enclosure Polycarbonate, IP 65 (Shown in Figure 1)
Size: 6.3 inches x 6.5 inches wide x 5.2 inches deep
Weight: 3 pounds
Mounting: Wall
Enclosure
(optional)
NEMA-4X, certifiable (Shown in Figure 1A)
Size: 4.5 inches x 8.0 inches wide x 5.5 inches deep
Weight: 3 pounds
Mounting: Wall
Input Power Supplied with a 110 V AC line cord
85-265 V AC , 24 V DC
Display LCD: 1x8, Hitachi 44780 compatible
Power LED Power On: Green LED
Audio Alarm A Sonalert horn, with on-off switch and red indicator LED.
Visual Alarm Alarm Levels: Three programmable levels, a red LED for each alarm level
Pushbutton Switch For automatic zeroing and calibration
Specifications Description
Output 4-20 mA
Alarms: One of the three alarms, selectable by jumper, operates the horn and relay
Alarm signals: 0 or 5
V DC are available for limited application, such as computer inputs
Temperature –20C to +50C. Observe limitation on the sensor of the associated sensor/transmitter.
Programming Programmed per order
Humidity Generally 0-95% RH, noncondensing
Relays 2 Amp at 120 V AC , at one alarm level in conjunction with horn, contacts available on terminal
strip
N OTE : All specifications stated in this manual may change without notice.
