6
Master and Slave Clock Operation
In Master mode (switch set to INT) the DAC6e provides the clock to the
audio source. A cable needs to be connected from either the BNC Clock
output or Optical Clock output from the DAC6e to the clock input of your
audio source. This mode provides the best audio performance as the clock
jitter is minimzed.
In Slave mode (switch set to EXT) the DAC6e locks to the clock as provided
by the selected audio source (DSD or PCM).
Channel assignment when using EMM OptiLink to connect a CDSD to the DAC6e
The CDSD can play back up to 6 channels from SA-CD when combined with
the DAC6e converter. In this case the analog output channels of the DAC6e
have the following channel assignment:
Channel 1: Left front
Channel 2: Right front
Channel 3: Center front
Channel 4: Low Frequency Subwoofer
Channel 5: Left rear surround
Channel 6: Right rear surround
Specifications
Output Line Levels (with 0dBfs signal on AES/EBU input)
XLR balanced: +17.35dBu / +15.13dBv / 5.71V
RCA unbalanced: +12.89dBu / +10.67dBv / 3.42V
