CDSA User Manual
CDSA Disc Player
The CDSA is a disc player for CD and stereo SA-CD. While it does play the mulichannel
program of SA-CD discs it only provides 2 channels of analog output. As a unique
feature, the CDSA up-samples any PCM signal to twice the sample rate as it is used on
SA-CD’s before converting it to the analog output.
Features
• Supported disc formats:
• Redbook CD
• Stereo SA-CD
• MP3
• Digital output: AES/EBU
• Analog
outputs:
• Impedances: 100Ω balanced (XLR), 50Ω unbalanced (RCA)
• 2 user selectable levels:
Low position: XLR outputs: 4V (+14.38dBu)
RCA outputs: 2V (+8.353dBu)
High position: XLR outputs: 7.2V (+19.38dBu)
RCA outputs: 3.6V (+13.34dBu)
Note: XLR outputs are balanced with pin 2 hot (+), pin 3 cold (-) and pin 1 ground.
• Proprietary MDAT technology for upsampling CD playback to 5.6MHz
• Proprietary Dual Differential DAC Circuit (not based on any standard off-the-shelf
available DAC chip).
• Exclusive Composite Laminate Circuit Boards
• System control via Infrared remote and serial RS-232
• USB port for future software upgrades (see Appendix B)
• Power supply
• Power factor corrected
• Factory set to 100V or 115V or 230V, 50/60Hz
• Power consumption: max. 60W
• Dimensions W x D x H: 435 x 400 x 140mm
• Weight:
12kg
3
