Appendix A - Serial Remote Control (RS232)
© 2010 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
DAC2 AUDIO CONVERTER OWNER’S MANUAL
Commands to the DAC2 (cont`d)
Status bytes sent from DAC2
The DAC2 sends back 4 Bytes terminated with a
Byte 0 ASCII ' 0 ' - Not Used
Byte 1 ASCII ' 0 ' - Not Used
Byte 2
bit 0 Not Used
bit 1 Not Used
bit 2 Status of EMM Link input (0 when selected)
bit 3 Status of USB input (0 when selected)
bit 4 Status of AES input (0 when selected)
bit 5 Status of Coax input (0 when selected)
bit 6 Status of TOS1 input (0 when selected)
bit 7 Status of TOS2 input (0 when selected)
Byte 3
bit 0 Lock Status, 1 when locked
bit 1 Not Used
bit 2 0 when 44.1kHz selected as base sample frequency
bit 3 0 when 48kHz selected as base sample frequency
bit 4 Status of polarity of analog outputs (0 when inverted)
Command
Function
usb
Selects USB PCM audio via USB interface
