Appendix A - Serial Remote Control (RS232)
Commands to the TSDX (cont`d)
pol
Toggles polarity inversion performed in the digital domain.
Status bytes sent from TSDX
The TSDX sends back 9 Bytes terminated with a
Byte 0 Seconds ones in ASCII
Byte 1 Seconds tens in ASCII
Byte 2 Minutes ones in ASCII
Byte 3 Minutes tens in ASCII
Byte 4 Hours ones in ASCII
Byte 5 Track number ones in ASCII
Byte 6 Track number tens in ASCII
Command
Function
dim
Toggles through display brightness settings
try
Tray open and close
tr(x)
tr followed by a single digit (x) to jump to a particular track. See example.
tr(x) example:
a) Jump to track 5
:
tr0
b) Jump to track 12 :
tr1
