Operation

DAC2X AUDIO CONVERTER OWNER’S MANUAL

Basic Operations and Input Connections

1. Memory:

After 10 seconds when no button has been pushed or changed, the DAC2X

memorizes its momentary setup in permanent memory for later retrieval after the

next powerup. It will be recalled immediately after the unit is turned on. Each

individual input selection will keep its last configuration before powerdown.

During normal operation each input selection will immediately memorize its

configuration so that switching between different sources with different configurations

can be accomplished with a single button selection.

2. DAC2X Input Connections:

Just connect the appropriate digital source output to the specific DAC2X input, on the

back of the DAC2X and select the appropriate digital source from either the front

panel buttons or the remote control.

Typical front panel display when DAC2X is locked to 44.1kHz base frequency and the
