Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, network and wireless software,
user's manuals, safety manual
Optional
Accessories
USBWL11N USB wireless adapter,
TB-1 wireless USB tablet
Optional Lenses NA
Replacement Parts
Lamp 456-8755N
Remote Control HL02881
Filter MU06481
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA - 1024 x 768
White Light Output 2,700 ANSI lumens
Color Light Output 2,700 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 16:9 / 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 1.8 : 1
Lens & Operation
Lens x1.2 with manual zoom
Lamp Wattage 215W UHP
Expected Lamp Life* Approximately 5,000 hours (standard mode)
6,000 hours (Eco mode)
Expected Filter Life** Approximately 5,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 36 dB (29 dB in Eco mode)
Keystone +/- 30º vertical only
Compatibility
Computer VGA, XGA, WXGA, WXGA+, SVGA, SXGA+,
UXGA (compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video
Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2 (shared w/analog computer 1/2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 100-base-T
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & W
arranty
Power Supply AC90-132V / AC198-264V, 50/60Hz
Power Consumption 310W
Operating Temperature 40ºF - 95ºF (5ºC - 35ºC)
Dimensions (W x D x H) 12.5" x 11.3" x 3.9" / Shipping 18.0" x 15.0" x 8.0"
Weight 8.15 lbs. / Shipping 14.0 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class B
Warranty Five (5) year limited warranty plus Dukane’s 1 year Peace of
Mind Loaner Program
UPC 00000060519400260
Projection Throw Chart
Screen Size 4:3 Throw Distance
Diagonal Width Min Max
30 24 32 39
60 48 68 82
80 64 92 111
100 80 116 140
150 120 175 211
200 160 235 283
300 240 354 426
Throw Ratio: 1.5 - 1.8 : 1 (distance : width)
Screen size and throw distance are measured in inches.
8928
8928 LCD Projector
Specifications subjext to change without notice.
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
