Technical Specifications EMC 1UP
The following technical data were measured on randomized test objects and are
typical data. All measurements are made at 120V / 240V // 50Hz / 60 Hz.
Analog stage
Measurements
Parameters
Single ended
Balanced
Output level
(RMS)
1.6 V
3.2 V
Gain
1.6 X (4 dB)
3.2 X (10 dB)
Maximum output
(RMS)
> 7 V
>14V
THD
(1 V out, 1 kHz)
< 0.002 %
Channel separation
(1 V out, 1 kHz)
> 90 dB
Equivalent input noise
4 uV
Digital stage
Dynamic range
100 dB
Signal to noise
100 dB
THD
-100 dB
Frequency response
(20 - 20 kHz)
0 dB
Output
S/PDIF
Power consumption
23 W
The EMC 1UP has DC coupled analog output
Dimensions
Width
483 mm
-
19 inch
Depth
450 mm
-
17.7 inch
Height
120 mm
-
4.7 inch
Weight
20 kg
-
44 lbs
Specifications subject to change without notice.
