Technical Specifications: ECP1
The following technical data were measured on randomized test objects and were typical
data. All measurements are made with the following equipment:
Distortion analyzer:
Tektronix M50 1
Oscilloscope: Tektronix 468
Oscillator: Tektronix 5G505
Frequency counter: Rascal 9838
Phase meter: Hewlett Packard 3575A
Phono stage
Phono input to record output
Gain 1 KHz Moving Coil (source impedance = 10 ohm)
73 dB (4500x)
Gain 1 KHz Moving Magnet 34.8 dB (55x)
Input Impedance Moving Magnet 47 Kohm/22pF
THD 1 KHz (2V output) less than 0.007%
Overload 1 KHz Moving Coil (THD = 0,2%) more than 2 mV
Overload 1 KHz Moving Magnet )THD = 0,2%) more than 165mV
Channel separation )iV output at 1 KHz) more than 80dB
Noise ref. 0,5 mV) Moving Coil -88 dB
Noise (ref. 5 mV) Moving Magnet -88 dB
Equivalent input noise 400 Hz - 300 KHz) 0,2 uV
RIM Accuracy (20 Hz - 20 KHz) +/-0,1 dB
Output impedance 100 ohm
Dimensions
Width
240mm (9.5 inches)
Depth 165 mm (6.5 inches)
Height 65 mm (2.5 inches)
Weight 2.2 kg (4.4lbs)
