OPERATOR INSTRUCTIONS ANd PARTS
CRT Models 6014V
Page 11
GetEarthquake.com
800-345-6007
WhEEL LOCk PINS
Place wheels in tilling position.
1. Remove lock pin. Align hole in axle with hole in wheel hub.
(SEE
FIGURE )
2. Insert lock pin through holes, fold lock pin ring to secure pin to
axle.
3. Firmly lock wheel and axle together before tilling.
4. Repeat for other wheel.
NOTE: Always have both wheel lock pins in or out. Do not
operate tiller with only one wheel locked.
To place wheels in free-wheel position.
1. Remove lock pin. Slide wheel inward toward machine.
2. Insert pin in axle only.
3. Wheel should turn freely on axle.
Wheel lock pin in free-wheel position.
(axle hole only)
NEvER START ENGINE OR OPERATE TILLER
WITh WhEELS IN FREE-WhEEL POSITION. ThE
FREE-WhEEL POSITION IS FOR TRANSPORTING
ThE TILLER LONG dISTANCES OvER LEvEL
GROUNd-dO NOT ATTEMPT TO MOvE ThE TILLER
UP OR dOWN STEEP GRAdES IN ThE FREE-WhEEL
POSITION.
WARNING !
FIGURE
