Operator’s Manual
Badger 20908 Front Tine Tiller
ILLUSTRATED PARTS BREAKDOWN -
MOTOR MOUNT AND HOOD PARTS
ITEM
NO.
PART #
DESCRIPTION
QTY.
1
20889
ENGINE & PULLEY GROUP
METRIC KOHLER FT
1
2
400023
NUT M8 NYLOCK
4
3
20894
SPACER, ENGINE
23x30x14.317MM
1
4
3364
KEY, SQUARE 3/16” X 5/8”
1
5
20907
PULLEY SINGLE GROOVE
ENGINE 4L OFFSET
1
6
3245
WASHER M8 8.4MM X 24MM X
2.2MM ZN
1
7
21035
BOLT 3/8-24 X 1.5 W/PATCH
SHBHCS
1
8
20820
BOLT M10 X 1.5 X 16 HHSF GR8.8
ZN
4
9
4650
NUT M6 X 1.0 HNYLK GR8.8 YL
ZN
12
10
20824
BOLT M6 X 1.0 X 190 HHCS
GR8.8 ZN
2
11
18130
WASHER M6 X 1.5 SPRLCK ZN
2
12
3130A
FRAME ENGINE MOUNT FT
FORMED
1
13
20816
BOLT M8 X 1.25 X 35 HHCS
GR8.8 ZN
1
14
17986
BOLT M6 X 1.0 X 16 HHCS GR8
ZN
10
15
20148
WASHER M6 X 18 X 1.6 FLAT ZN
4
16
3335
ARM LOWER HANDLEBAR FT
BUMPER
1
17
3371
COVER 4 HOLE FT
1
18
744
SPACER FORWARD ARM 10.5 X
22 X 14.5 MM
2
19
20834
BELT GUIDE AND MOUNT
METRIC 3365 SERIES
1
20
20144
BOLT M8 X 1.25 X 60 HHCS GR
8.8 ZN F-T
2
ITEM
NO.
PART #
DESCRIPTION
QTY.
21
1407
SPRING, FORWARD ARM
1
22
53398
PIN, COTTER 2MM X 16MM
1
23
1416
PIN CLEVIS 6.3 X 16.8 MM
1
24
53596B
YOKE ZINC PLATED CLEVIS
1
25
2431
WASHER M10 X 20 X 2 THK GR
8.8 ZN
1
26
400024
WASHER M8 8.4 X 16 X 1.6 THK
ZN
1
27
20835
ARM FORWARD METRIC 3365
SERIES
1
28
W1200126
WASHER M10 X 28 X 2.8 ZN
2
29
1413
PULLEY, REVERSE IDLER
1
30
13559
WASHER M10 SPRING LOCK
1
31
W1265V0903
NUT M10 X 1.5 HNYLK GR 8.8 ZN
1
32
14978
BELT V 4L 675 MM
1
33
3275
SHIELD FRONT TINE FRAME
1
34
3128
TINE SHIELD W/O BRACKETS
FORMED FT
1
35
20173
PIN COTTER HAIRPIN 2.5MM
DIA. X 35MM
4
36
50175
WASHER 12MM TILLER
4
37
3332
SHAFT TAIL PIVOT
1
38
3331
SHAFT, WHEEL 1/2”
1
39
1714252 WHEEL & TIRE ASSY 11.0 X 1.75
2
40
18039
PIN LOCK 8MM X 40MM PIPE
SAFETY PIN
1
41
3157
DRAG STAKE FRONT TINE
1
42
3330
TAIL MOUNT, LOWER FOR FT
1
43
20799
TAIL MOUNT UPPER FRONT TINE
METRIC
1
44
21246
SPACER 22.5 X 31.9 X 1.5 MM
2
